| Nominal Voltage: | 24V | Nominal Capacity: | 200Ah |
|---|---|---|---|
| Energy: | 5120Wh | Chemistry: | Lithium Iron Phosphate (LiFePO4) |
| Max Discharge Current: | 100A | Water-proof Level: | IP65 |
| Discharge Temperature: | -20°C-55°C | Dimensions: | 522 X 268 X220 Mm |
| Certifications: | CE/UN38.8/MSDS/RoHS | Warranty: | 10 Years |
| High Light: |
200Ah Lithium Iron Phosphate Battery, 5120Wh Lithium Iron Phosphate Battery, 24V Lithium Iron Phosphate Battery |
||
| Model No. | YX24200 |
| Nominal Voltage | 25.6 V |
| Nominal Capacity | 200Ah |
| Energy | 5120Wh |
| Resistance | ≤80 mΩ @ 50% SOC |
| Module Parallel or series(for option) | Up to 4packs |
| Bluetooth function | For option |
| Recommended Charge Current | 40A |
| Maximum Charge Current | 50A |
| Recommended Charge Voltage | 29.2V |
| BMS Charge Cut-Off Voltage | <29.2 V (3.65V/Cell) |
| Balancing Starting Voltage | 3.4V/Cell |
| Maximum Continuous Discharge Current | 100A |
| Peak Discharge Current | 300 A (1s) |
| Recommended Low Voltage Disconnect | 20 V (2.5V/Cell) |
| BMS Discharge Cut-Off Voltage | 16V (2.0V/Cell) |
| Short Circuit Protection | ＜350 μs |
| Dimension (L x W x H) | 522 x 268 x220 mm 20. 6x10.55 x 8.66” |
| Approx. Weight | 85.98lbs(39Kg) |
| Terminal Type | M8 terminal |
| Terminal Torque | 80 ~ 100 in-lbs (9 ~ 11 N-m) |
| Case Material | ABS+PC |
| Enclosure Protection | IP65 |
| Discharge Temperature | -4 ~ 131 ºF (-20 ~ 55 ºC) |
| Charge Temperature | -4 ~ 113 ºF (0 ~ 45 ºC) |
| Storage Temperature | 23 ~ 95 ºF (-5 ~ 35 ºC) |
