YX-TPF20GA

  • YX-TPF20GA
  • LFP Prismatic  battery cell>YX-TPF20GA
Part number YX-TPF20GA
Product classification 179
Manufacturer
Description -
Encapsulation -
Quantity 1000
RoHS status YES
Share
Price $
IN STOCK: 1000
Total number

Quantity

Price

Total price

Obtain quotation information
Product parameters

1 Model Number: TPF20GA

2 Typical Capacity: 20Ah

3 Nominal Voltage: 3.2V

4 Standard Charging: CC/CV, 1C, 3.65V

5 Standard Discharging: CC, 1C, 2.0V

6 Cut-off Discharge Voltage: 2.0V

7 Maximum Continuous Discharge Current: 600A (30C)

8 Maximum Peak Discharge Current: 35C for 30 seconds

9 Maximum Continuous Charging Current: 120A (6C)

10 Initial Impedance: ≤0.5mΩ

11 Operating Temperature: Charging: -20°C to 45°C, Discharging: -43°C to +60°C

12 Storage Temperature: -40°C to +60°C

13 Storage Humidity: ≤70% RH

14 Dimensions: 27*148*95 mm

15 Weight: 725±20 grams

Place of Origin: China Certification: CE/UN38.3/MSDS
