YX15KVA

  • YX15KVA
  • UPS series>YX15KVA
Part number YX15KVA
Product classification 194
Manufacturer
Description Place of Origin: China Certification: CE/UN38.3/MSDS
Encapsulation -
Quantity 1000
RoHS status YES
Share
Price $
IN STOCK: 1000
Total number

Quantity

Price

Total price

Obtain quotation information
Product parameters
Battery Voltage: DC 384V Battery Capacity: 80Ah
AC Output Voltage: AC Three-phase 380V/400V/415V Frequency: 50/60Hz
Discharging Temperature: -40°C ~ +60°C Charging Temperature: 0°C ~ +60°C
High Light:

15 KVA Low Temperature UPS, DC 384V Low Temperature UPS





UPS 15 KVA ) host performance parameters

Technical Parameters
model PT-15KS
Brand /
AC input Phase Three-phase
frequency 50Hz ~ 60Hz ( customer confirmation )
voltage range 380VAC ± 10%
AC output rated power 15 KVA (1 2 KW)
Rated voltage AC Three-phase 380V/400V/415V
Voltage accuracy ± 2%
frequency Rate 50Hz / 60Hz ( Confirmed by customer )
Online double conversion mode efficiency 96%
Dynamic Response 5% (0%~100% load)
Crest Factor (CF) 3:1
Power Factor 1.0
Inverter efficiency ≥ 85%
Alarm LED indicator alarm and LCD display text alarm
Conversion time Online
recharging current ≤ 50A±5A
noise ≤60db
Dielectric strength 1500VAC, 1min (input and output)
IP grade IP20
cooling method Fan cooling
Dimensions L×W×H (mm) 4 38 *129* 589



30 KWH lithium battery pack performance parameters

No. Item Specifications
1 Battery Pack Model ES 384080 F01
2 Battery Type Lithium iron phosphate battery
3 Typical voltage DC 384V
4 Typical Capacity 80 AH (standard test: 25±5℃ environment, 0.2C discharge)
5 Minimum capacity 78 Ah (standard test: 25±5℃ environment, 0.1C discharge)
6 Rated energy 30K WH
7 Charge cut-off voltage 465 ± 2 V
8 Discharge cut-off voltage 320 V ± 2 V
9 Shipping voltage > 380 V
10 Standard charging method Charge with a constant current of 1.6 A until 465 V or automatic protection, switch to constant voltage charging, cut-off current 1.6 A (ambient temperature 25±2℃)
11 Standard discharge method Discharge at a constant current of 16 A until the battery is protected (ambient temperature 25±2℃)
12 Maximum continuous charging current ≤ 20 A (ambient temperature: -40℃ ~ 60 ℃) (with heating function)
13 Maximum continuous discharge current ≤ 50A (ambient temperature: -40℃ ~ 60 ℃)
14 Instantaneous discharge current ≤ 150A (3S) (ambient temperature: -40℃ ~ 60 ℃)
15 Cycle life ≥1500 times, capacity ≥80% (standard charge and discharge mode)
16 Design life 5 years
17 Working temperature

Charging: 0℃~60℃ ( 20 A charging) (Heating first when below 0℃, charging starts above 0℃)

Discharge: -40~0℃ ( 20A discharge)

0~45℃( 50A discharge)

45~60℃( 40A discharge)

Handheld Multi-Tool Counter-UAV Device - 12 Bands
Shield Countermeasure Device - 8 Band
Place of Origin: China Certification: CE/UN38.3/RoHS/MSDS
Place of Origin: China Certification: CE/UN38.3/MSDS
Place of Origin: China Certification: CE/UN38.3
Place of Origin: China Certification: CE/UN38.3
Shenzhen PCB Gerber File Making PCB And Bom List Layouting Services Provider PCB PCBA
